| Level Use Group | B | C | D |
| Rated Voltage Rate Voltage [V] | 600 | 600 | 600 |
| Rated current | 30 | 30 | 5 |
| Wire Range [AWG] | 24~10 | ||
| Contact Resistance | 2.2kv | ||
| Overvoltage Category | Ⅲ | Ⅲ | Ⅱ |
| Contamination Class | 3 | 2 | 2 |
| Rated Voltage [V] | 800 | 1000 | 1000 |
| Rated Current [A] | 41 | 41 | 41 |
| Impulse withstand voltage [KV] | 8 | 8 | 8 |
| Conductor cross section [mm2] | 0.2~6.0/0.2~4.0 | ||
| Insulation Material | PA66 |
| Flame relardant rating | UL94V-0 |
| Conductor Material | Copper alloy |
| Plating of conductor surface | Sn Plated |
| Pitch/Poles [mm]/[P] | 6.35/2~18 |
| Stripping Length [mm] | 8 |
| Screw/Torque(Max)[N.m] | M3/0.5 |
| Operating temperature [℃] | -40~+105 |
| Soldering temperature | 250℃/5S |
| Pin dimensions [mm] | 0.9*0.9 |
| PCB Hole Diameter [mm] | ∅1.5 |
